UltraNanoShield's premium paint protection films offer military-grade protection with self-healing technology, unmatched clarity, and long-lasting durability. Protect your investment with our scientifically engineered films.
Current manufacturer specifications and warranty programmes
| Product | Thickness | Warranty |
|---|---|---|
| Clear Protect - U115 | 185 µm | 5 years limited warranty |
| Clear Standard - U116 | 190 µm | 6 years limited warranty |
| Clear Atmark - U118 | 195 µm | 7 years limited warranty |
Detailed technical specifications for our complete range of premium paint protection films
| Specification | Clear Protect - U115 | Clear Standard - U116 | Clear Atmark - U118 | Crystal Clear Pro - R119 | Clear High Impact - A210 | PCU-X10 | Life Time - N220 | TPU Matte | Pro Matte Platinum | Super Glossy Black |
|---|---|---|---|---|---|---|---|---|---|---|
| Total film thickness | 185 µm | 190 µm | 195 µm | 198 µm | 220 µm | 200 µm | 220 µm | 190 µm | 195 µm | 195 µm |
| Gloss | 140 GU | 144 GU | 146 GU | 148 GU | 152 GU | 160 GU | 155 GU | Not listed | Not listed | 146 GU |
| Tensile strength | 23 MPa | 24 MPa | 25 MPa | 27 MPa | 29 MPa | 29 MPa | 30 MPa | 45 MPa | 48 MPa | 35 MPa |
| Elongation | ≥ 330% | ≥ 345% | ≥ 348% | ≥ 350% | ≥ 360% | ≥ 360% | ≥ 370% | ≥ 500% | ≥ 510% | ≥ 380% |
| 100% modulus | 8.2 MPa | 8.2 MPa | 8.2 MPa | 8.2 MPa | 8.2 MPa | 8.2 MPa | 8.2 MPa | 5.6 MPa | 5.8 MPa | 8.2 MPa |
| Tear strength | 72 kN/m | 73 kN/m | 75 kN/m | 77 kN/m | 85 kN/m | 83 kN/m | 88 kN/m | 75 kN/m | 78 kN/m | 75 kN/m |
| Coating elongation | 120% | 125% | 127% | 129% | 140% | 145% | 144% | 150% | 155% | 127% |
| Peel strength - 20 min | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm | 16 N/25 mm |
| Peel strength - 24 h | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm | 20 N/25 mm |
| Gravel impact resistance | Pass | Pass | Pass | Pass | Pass | Pass | Pass | Pass | Pass | Pass |
| Self-healing performance | Self-healing | Self-healing | Self-healing | Self-healing | Self-healing | Self-healing | Self-healing | Self-healing | Self-healing | Self-healing |
| Anti-yellowing | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 | ΔE ≤ 2 |
| Material architecture | Mounting Adhesive → Release Liner | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed |
| Application | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation | Professional wet-installation |
| Warranty | 5 years limited warranty | 6 years limited warranty | 7 years limited warranty | 8 years limited warranty | 10 years limited warranty | 10 years · includes accidental damage on up to 2 panels | Life Time · includes accidental damage on up to 4 panels | 5 years limited warranty | 7 years limited warranty | 7 years limited warranty |
| Matte finish | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed | Not listed | 12 GU Matte | 12 GU Matte | Not listed |
| Specification | Windshield Defense Pro | Sunroof Armor |
|---|---|---|
| Visible Light Transmission | ≥ 90% - ASTM D1003 | Not listed |
| Optical Haze | ≤ 1.0% - ASTM D1003 | ≤ 1.5% |
| UV Rejection | ≥ 99% - UV Spectrophotometry | Not listed |
| Tensile Strength | ≥ 35 MPa - ASTM D882 | ≥ 30 MPa |
| Elongation at Break | ≥ 200% - ASTM D882 | ≥ 200% |
| Water Contact Angle | ≥ 100° - ASTM D7334 | ≥ 100° if hydrophobic |
| Peel Adhesion | ≥ 500 gf/in - ASTM D3330 | ≥ 500 gf/in |
| Yellowness Index | ≤ 2.0 - ASTM E313 | Not listed |
| Surface Gloss (60°) | ≥ 90 GU - ASTM D2457 | ≥ 90 GU |
| Total film thickness | 190 µm (7.5 mil) | 7.6 mil |
| Warranty | 2 years limited warranty | 7 years limited warranty |
| Visible Light Transmission (VLT) | Not listed | ≥ 70% for clear variant |
| Infrared Rejection (IRR) | Not listed | ≥ 90% at specified wavelength |
| Ultraviolet Rejection (UVR) | Not listed | ≥ 99% |
| Total Solar Energy Rejection (TSER) | Not listed | ≥ 50% |
| Yellowing Resistance | Not listed | Supplier Aging Test |
| Impact Resistance | Not listed | Supplier Impact Test |
| Glass Fragment Retention | Not listed | Supplier Glass Retention Test |
| Thermal Stress Compatibility | Not listed | Glass-Specific Validation |
